Grade 5 Titanium Plate Sheet
|
Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | JINXING |
| Certification: | ISO 9001 |
| Model Number: | Titanium Tube |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 5Kgs |
| Price: | 15~150USD/kg |
| Packaging Details: | Plywood Case |
| Delivery Time: | 10~25 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 100000kgs/M |
|
Detail Information |
|||
| Material: | GR1 GR2 GR3 GR4 GR5 GR7 GR9 GR23, Etc | Standard: | ASTM B337,ASTM B338,ASTM B861,ASTM B862,DIN 17861 |
|---|---|---|---|
| Surface: | Pickled Or Polished Bright | Technique: | Titanium Welded Tube, Titanium Seamless Tube |
| Shape: | Round, Square | Size: | Customized |
| Type: | Cold Rolling , Forge Drilling | ||
| Highlight: | titanium alloy Tubes,ams 4911 titanium Pipes,Lightweight Titanium Alloy Tubes |
||
Product Description
JINXING company Titanium tubes and pipes are available in varying wall thicknesses and can be ordered to different lengths and specifications.Our capabilities can be used to customize your order-including stamping,welding and bending. Titanium Grade 1, Grade 2 , Grade 3 , Grade 5 , Grade 7 , Grade9 , Grade11 etc.
The titanium tube is light in weight, high in strength and superior in mechanical properties. It is widely used in heat exchange equipment such as tubular heat exchangers, coil heat exchangers, serpentine heat exchangers, condensers, evaporators and pipelines. Many nuclear power industries use titanium tubes as their standard units.
Standards:
ASTM B338-14
ASTM B861-14
| N | C | H | Fe | O | Al | V | Pa | Mo | Ni | Ti | |
| Gr 1 | 0.03 | 0.08 | 0.015 | 0.20 | 0.18 | / | / | / | / | / | bal |
| Gr 2 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | / | / | bal |
| Gr 3 | 0.05 | 0.08 | 0.015 | 0.30 | 0.35 | / | / | / | / | / | bal |
| Gr 4 | 0.05 | 0.08 | 0.015 | 0.50 | 0.40 | / | / | / | / | / | bal |
| Gr 5 | 0.05 | 0.08 | 0.015 | 0.40 | 0.20 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
| Gr 7 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
| Gr 9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | / | / | / | bal |
| Gr12 | 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 | bal |
Tests:
Seamless tubes and pipes are tested according to customers' quality
requirements:
1 Tension test
2 Flattening test
3 Bend test
4 Ultrasonic test
5 Eddy current test
6 Hydrostatic test
7 Pneumatic test
8 Electromagnetic test
9 Flaring test
10 Chemistry test
JINXING company Titanium tubes and pipes are available in varying wall thicknesses and can be ordered to different lengths and specifications.Our capabilities can be used to customize your order-including stamping,welding and bending. We have been selling Titainium tubes and pipes to Asia,North America and Europe.Our superior quality,quick delivery and good price will make you compete easier in your market.
